    PET Conductive Fiber Needle Punch Nonwoven Fabric

    Ask Lasest Price
    Brand Name : 17s
    Model Number : PETSSN550L
    Certification : ISO
    Price : negotiable
    Supply Ability : negotiable
    Delivery Time : TBD
    • Product Details
    • Company Profile

    PET Conductive Fiber Needle Punch Nonwoven Fabric

    550g PET And Conductive Fiber Blending Needled Felt Anti-Static Punch Felt Membrane PET Needled Filter Fabric


    Description

    Polyester needle felt is the most versatile, most cost effective and most widely used filter medium for dust collection. It is strong, abrasion resistant, can work up to 150°C and has good resistance to common acids, solvents and oxidising agents.


    Polyester's only real weakness is a tendency to hydrolyse at elevated temperature which means that moisture can break down the fibres and cause them to revert to their basic constituents. This results in powdering of the fibres and a serious loss of strength.


    Physical Data of PETSSN550L

    Item17SPETSSN550L
    NamePET and Conductive fiber blending needled felt 550g with PTFE membrance
    ConstructionNeedle-punched
    Fibre CompositionPET fiber+Conductive fiber
    Scrim CompositionPET filament
    Felt Area Weight550 ±25g/m2
    Thickness2.2±0.2mm
    Air Permeability2-5m3/m2/min@200Pa
    Breaking Strength-warp≥1000N / 5cm
    Breaking Strength-weft≥1300N / 5cm
    Breaking Elongation( N/5cm)-warp≤30%
    Breaking Elongation( N/5cm)-weft≤45%
    Electrical Resistivity≤106Ω
    Dry Shrinkage warp(150℃)<1.5%
    Dry Shrinkage weft(150℃)<1.0%
    Operating Temperatures
    Maximum Continuous130deg C
    Maximum Surge150deg C
    FinishHeat setting,Singing,Plain Finish,PTFE Membrance


    Chemical Resistance

    HydrolysisBiological (mildew, bacteria)AlkalisMineral AcidsOrgnic AcidsOxidising AgentsOrgnic Solvents
    restrictno effectfairfairfairgoodgood

    Application

    Because of its favourable price/quality ratio, polyester is the most common fibre used in filter media.

    • Mining
    • Cement Industry
    • Iron and Steel Industry
    • Aluminum and Non Ferrous Industry
    • Ceramic Industry
    • Quarrying
    • Plastics
    • Milk Powder
    • Flour Mills (Applications under dry conditions up to temperatures of 150°C)
