    2.5um PTFE Membrane Filter Bags Micro Porous Improved

    PTFE Membrane Filter Bag PTFE Lamination Dust Collect Bag PTFE Micro Porous Improved Cage Bag

    Specification
    PTFE micro porous membrane can effectively filter our 2.5um size dust, first of all solutions to PM2.5 emissions concentration under various working conditions and ensure below 10mg/Nm3 after important way. We cooperate with famous domestic PTFE micro porous membrane manufacturers, select high and low resistance three-dimensional micro porous research and development production of all kinds of coated filter bag, can meet customers’ net emission.


    Features of the various filter bags

    NamePPS and PTFE blending needled felt bag 650g with laminationPET needling cloth bag 550g with PTFE laminationPET and Conductive fiber blending needled felt bag 550g with PTFE membrance
    ConstructionNeedle-punchedNeedle-punchedNeedle-punched
    Fibre Composition50% PPS fiber+50%PTFE fiberPET fiberPET fiber+Conductive fiber
    Scrim CompositionPTFEPET filamentPET filament
    Area Weight650g/m2550 ±25g/m2550 ±25g/m2
    Thickness1.7 ± 0.2mm2.2±0.2mm2.2±0.2mm
    Air Permeability2-5m3/m2/min@200Pa2-4m3/m2/min@200Pa2-5m3/m2/min@200Pa
    Breaking Strength-warp≥800N / 5cm≥1000N / 5cm≥1000N / 5cm
    Breaking Strength-weft≥1100N / 5cm≥1500N / 5cm≥1300N / 5cm
    Breaking Elongation( N/5cm)-warp≤25%≤30%≤30%
    Breaking Elongation( N/5cm)-weft≤45%≤50%≤45%
    Dry Shrinkage warp(190℃)<1.5%<1.5%<1.5%
    Dry Shrinkage weft(190℃)<1.0%<1.0%<1.0%
    Operating Temperatures
    Maximum Continuous170deg C130deg C130deg C
    Maximum Surge200deg C150deg C150deg C
    FinishHeat setting, Singing,Plain FinishHeat setting,Singing,MembranceHeat setting,Singing,Plain Finish,PTFE Membrance

    Applications of the filter bag in the bag house

    PlantStar Bag MaterialApplication
    Aluminium PlantPEelectrolysis fume
    PPSaluminum hydroxide calcination
    Cement PlantPEcement mill, crushing macine, leather belt etc
    PE with antistaticcoal mill
    P84kiln back end
    Meta aramidkiln head
    Power SationPPSboiler tail gas
    Steel PlantPEcasting house, ore bunker, sintering machine end, finished product transportation
    Acrylicslag differential
    Meta aramidrotary furnace
    PPS/Acrylicsintering machine head
    Chemical PlantPTFE , Meta aramidhigh temperature and corrosive confition
    Nonferrous Metal Smelt PlantP84aluminum metlting, copper furnace, gold smelt etc
    Carbon Black PlantPE, PE with PTFE laminationgrinder machine
    Glass PlantPTFE, PTFE composited P84 bag


    Package

    Packaging DetailCarton+Pallet , Polybag+ Pallet, or according to requirments
    DeliveryNormally 30 days after depsoit and PO placed
    Shipping TermsFOB Shanghai, CIF delivery port
